The 2023 CVO Road Glide Limited Anniversary model is an extremely limited, serialized custom bagger loaded with exclusive details, power and styling that celebrate 120 years of Harley-Davidson motorcycles. It’s the ultimate ride to the H-D Homecoming™ event. OVERVIEW Bold 120th anniversary themed paint Heated seats and grips Twin-Cooled™ Milwaukee-Eight 117 V-Twin Powertrain
Anniversary Black and Heirloom Red paneled paint scheme hand-laid details.
Luxurious Alcantara surfaces with gold and red contrast stitching accents and an embroidered CVO logo.
To commemorate the 120th anniversary, each motorcycle features a laser etched serialization on console insert.
Glass-filled Art Deco rendition of a flying eagle–iconic symbolism of Harley-Davidson, adorns each side of the tank.
| CUSTOM TWO-TONE COLORN/A | 120TH ANNIVERSARY$65,999 |
| ABS OPTIONStandard | SECURITY OPTIONStandard |
| CRUISE CONTROL OPTIONStandard | PREMIER RADIO OPTIONStandard |
| CALIFORNIA EMISSIONSN/A | TRANSPORT$1,050 |
| SURCHARGE$1,500 |
| ENGINETwin-Cooled™ Milwaukee-Eight™ 117 | BORE103.5 mm |
| STROKE 114.3 mm | DISPLACEMENT1,923 cc |
| COMPRESSION RATIO10.2:1 | FUEL SYSTEMElectronic Sequential Port Fuel Injection (ESPFI) |
| EXHAUSTDual, with crossover |
| LENGTH2,570 mm | SEAT HEIGHT, UNLADEN760 mm |
| GROUND CLEARANCE130 mm | RAKE26 |
| TRAIL170 mm | WHEELBASE1,625 mm |
| TIRES, FRONT SPECIFICATIONBW 130/60B19 61H | TIRES, REAR SPECIFICATIONBW 180/55B18 80H |
| TIRE, TYPEDunlop™ Harley-Davidson Series, bias blackwall front and rear | FUEL CAPACITY22.7 l |
| OIL CAPACITY (W/FILTER)4.7 l | WEIGHT, AS SHIPPED420 kg |
| WEIGHT, IN RUNNING ORDER437 kg | LUGGAGE CAPACITY -VOLUME0.132 m3 |
| ENGINE TORQUE TESTING METHODJ1349 | ENGINE TORQUE169 Nm |
| ENGINE TORQUE (RPM)3500 | HORSEPOWER102 HP / 76 kW @ 4750 rpm |
| LEAN ANGLE, RIGHT (DEG.)34.3 | LEAN ANGLE, LEFT (DEG.)33.4 |
| FUEL ECONOMY TESTING METHODEstimated City/Hwy | FUEL ECONOMY5.7 l/100 km |
| PRIMARY DRIVEChain, 34/46 ratio | GEAR RATIOS (OVERALL) 1ST9.593 |
| GEAR RATIOS (OVERALL) 2ND6.65 | GEAR RATIOS (OVERALL) 3RD4.938 |
| GEAR RATIOS (OVERALL) 4TH4 | GEAR RATIOS (OVERALL) 5TH3.407 |
| GEAR RATIOS (OVERALL) 6TH2.875 |
| FRONT FORK49mm Dual Bending Valve | REAR SHOCKSPremium standard height hand-adjustable rear suspension |
| WHEELS, FRONT TYPEGloss Black and Contrast Chrome Tomahawk | WHEELS, REAR TYPEGloss Black and Contrast Chrome Tomahawk |
| BRAKES, TYPE Dual floating rotors (front), fixed rotor (rear) | BRAKES, CALIPER TYPE32 mm, 4-piston fixed front and rear |
| LIGHTS (AS PER COUNTRY REGULATION), HEADLAMP, TAIL/STOP, FRONT SIGNAL LIGHTSLED 34-watt, 915 lumen low beam, 37-watt, 915 lumen high beam; LED | GAUGESCustom gauges styled to complement each CVO vehicle. Display features odometer, trip A, trip B, range to empty and gear indicator; and larger tell-tale indicators |
| INFOTAINMENT SYSTEMBoom!™ Box GTS | TYPEFull Color TFT |
| SCREEN SIZE165 mm | USBUSB/MTP/iPod/iPhone |
| BLUETOOTHPhone/Media Supported |
